End ultrasonic spot welder: This machine is a multi-functional, high-performance, universal multi band ultrasonic hand-held power supply. This is an intelligent digital ultrasonic control power developed by our company. This series of products use perfect real-time digital frequency tracking technology, which makes the products have more stable and efficient performance. Simple man-machine interface configuration mode makes the product more convenient to use.

High end ultrasonic spot welding machine: before using the ultrasonic power supply, please be familiar with the user manual, understand the range of equipment parameters and use environment. In order to correctly install and use the machine, give full play to its function, and ensure safety. This ultrasonic is a multi band electric box, which can adjust the ultrasonic frequency of 28-40khz. It can be used flexibly with the corresponding transducer.

High end ultrasonic spot welding machine: ultrasonic power supply is a high voltage product. For your safety, please be sure to install, debug and adjust parameters by qualified professional mechanical and electrical engineering personnel.

Type	power （W）	Frequency	Welding time	Contains
UCE-HH300W	300W	20khz,28khz,30khz,35khz,40khz	0.1-3sec	generator , transducer ,horn,head
UCE-HH500W	500W	20khz,28khz,30khz	0.1-3sec	generator , transducer ,horn,head
UCE-HH900W	900W	20khz,28khz,30khz	0.1-3sec	generator , transducer ,horn,head
UCE-HH1000W	1000W	20khz,28khz	0.1-3sec	generator , transducer ,horn,head
UCE-HH1200W	1200W	20khz,28khz	0.1-3sec	generator , transducer ,horn,head
