28khz/40khz Multi Frequency Ultrasonic Generator
In view of the advantages of good effect, high efficiency and low cost of ultrasonic cleaning, ultrasonic cleaning machine is widely used in electronics, machinery, clocks, optics, medical treatment, chemical fiber, electroplating and other industries [1]. In the ultrasonic cleaning equipment, ultrasonic power supply is one of the important parts. Most of the existing ultrasonic power supply uses special integrated control chip (such as SG3525, TL494) or single chip microcomputer to generate PWM pulse signal. After power amplification, impedance and tuning matching, it drives the transducer to convert the electrical signal into mechanical vibration to generate ultrasonic. These two kinds of power supply have their own limitations. The former control method has slow dynamic response, inconvenient parameter adjustment and serious temperature drift [2]. The single-chip microcomputer directly generates PWM signal. Although it can obtain high precision and high stability control characteristics and realize flexible and diverse control functions, due to the limitation of its working frequency, the output PWM signal has low frequency resolution It is difficult to meet the fine-tuning of frequency. In view of the above problems of ultrasonic power supply, based on PWM technology, this paper develops a kind of digital ultrasonic power supply with stable performance, simple control adjustment and low cost by using single chip microcomputer and analog integrated circuit to form an intelligent control system.
We know that for the power supply of the ultrasonic cleaning machine, it can also be called the ultrasonic power supply. Generally, its function is to convert the DC power into the necessary high-frequency AC power for the equipment. Then for its external layout, there are also complicated circuits in the process of operation. We should carry out professional training at the time of application!
Item |
Power |
Input voltage |
Transducer suggested |
Remark: |
Ultrasonic generator |
300W |
AC220V
AC110V
|
50W*6pieces |
Frequency adjustable from 20khz to 40khz
Auto Tracing or manual Adjusting Optional
Timer setting |
|
600W |
50W*10pieces |
|
900W |
50W*18pieces |
|
1000W |
50W*20pieces |
|
1200W |
50W*24pieces |
|
1500W |
50W*30pieces |
|
1800W |
50W*36pieces |
|
2000W |
50W*40pieces |
|
2400W |
50W*48pieces |
Ultrasonic Transducer needs calculated = Total ultrasonic power/ each transducer power=quantities
Upon you place order,please left message the input voltage needs,if not,we will deliver as per each country standard. |
28khz/40khz Multi Frequency Ultrasonic Generator
