diy ultrasonic vibration generator 2000w 40khz

diy ultrasonic vibration generator 2000w 40khz,diy ultrasonic vibration generator 2000w 40khz,diy ultrasonic vibration generator 2000w 40khz

Item ID #

Ask a Question FAQ & Help Payment Methods Shipping Estimator Email To Us Print This Page

Description

diy ultrasonic vibration generator 2000w 40khz

Ultrasonic generator, also known as ultrasonic drive power, electronic box, ultrasonic controller, is an important part of high-power ultrasonic system. The function of ultrasonic generator is to convert the market electricity into high frequency alternating current signal matching with ultrasonic transducer and drive ultrasonic transducer to work. Generally speaking, switching power supply is widely used in high power ultrasonic power supply. Ultrasound power supply is divided into self-excited power supply and its excitation power supply, self-excited power supply is called ultrasonic analog power supply, its excitation power is called ultrasonic generator.

The ultrasonic generator generates a signal of a specific frequency, which can be either a sinusoidal signal or a pulse signal, which is the frequency at which the transducer operates. Usually, the ultrasonic frequency used in ultrasonic equipment is 20 KHz, 25 KHz, 28 KHz, 33 KHz, 40 KHz, 60 KHz, 80 KHz, 100 KHz or more, which has not yet been widely used.

Adopting advanced microcomputer control technology and brand-new circuit design concept, a new generation of special power source for multi-functional ultrasonic cleaning machine is introduced.

(1) the control box adopts digital frequency synthesis technology controlled by microcomputer and frequency automatic tracking.

(two) digital ultrasonic power can be adjusted continuously and used more flexibly. The power is stronger and more efficient.

(3) Perfect protection functions: overheat protection, overload protection and short circuit protection, stable performance.

(four) four timer, time control to seconds to ensure the quality of your work.

(five) a display of "working state", "frequency" or "time" can be displayed as required.

(six) with multi frequency conversion mode and frequency fine tuning function, the frequency range is wide and the versatility is strong.

(7) Can work 24 hours, stable performance, cleaning time can be adjusted 00-60 minutes, power size can be adjusted 0-100%, energy saving.

Type	Power（W）	Frequency (KHz)	Transducer numbers	Size
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE All of machine are available for opening remote control function to connect with your own PLC system
UCE-NT300	300W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	3-6	300x360x150
UCE-NT600	600W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	6-12	300x360x150
UCE-NT900	900W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	9-18	300x360x150
UCE-NT1000	1000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	10-20	300x360x150
UCE-NT1200	1200W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	12-24	300x360x150
UCE-NT1500	1500W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	15-30	300x360x150
UCE-NT1800	1800W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	18-36	300x360x150
UCE-NT2000	2000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	20-40	300x360x150
UCE-NT2400	2400W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	24-48	300x360x150
UCE-NT3000	3000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	50-60	300x360x150
High Frequency	300W-1200W	65-80khz
High Frequency	300W-1200W	120-135khz
