Multi-function ultrasonic generator,Multi-function ultrasonic generator for Multi-Function Ultrasonic Thickness

The acoustic power source (or generator) is a device for generating and transmitting ultrasonic energy to ultrasonic transducers. There are two ways to encourage the ultrasonic generator: one is his excitation, the other is self excitation. It can be divided into four types: electronic tube ultrasonic generator, silicon controlled inverter ultrasonic generator, transistor ultrasonic generator and power module ultrasonic generator. The electronic tube and SCR inverter are basically eliminated, and the transistor generator is widely used. His excitation ultrasonic generator mainly consists of two parts, the former is an oscillator and the latter is an amplifier. Generally, the ultrasonic energy is added to the transducer through the coupling of the output transformer. The self excited ultrasonic generator combines the oscillation, the power amplifier, the output transformer and the transducer to form a closed loop circuit, which satisfies the amplitude and phase feedback conditions, and forms a oscillator with power amplification.

Item	Power	Input voltage	Transducer suggested	Remark:
Ultrasonic generator	300W	AC220V   AC110V	50W*6pieces	Frequency adjustable from 20khz to 40khz   Auto Tracing or manual Adjusting Optional     Timer setting
	600W		50W*10pieces
	900W		50W*18pieces
	1000W		50W*20pieces
	1200W		50W*24pieces
	1500W		50W*30pieces
	1800W		50W*36pieces
	2000W		50W*40pieces
	2400W		50W*48pieces
Ultrasonic Transducer needs calculated = Total ultrasonic power/ each transducer power=quantities Upon you place order,please left message the input voltage needs,if not,we will deliver as per each country standard.
