ultrasonic bath power control generator

ultrasonic bath power control generator,ultrasonic bath power control generator,ultrasonic bath power control generator,ultrasonic bath power control generator,ultrasonic bath power control generator

Item ID #

Ask a Question FAQ & Help Payment Methods Shipping Estimator Email To Us Print This Page

Description

ultrasonic bath power control generator

The main functions of the ultrasonic generator are:

The output rate is adjustable: it can smoothly adjust the output power linearly, and can be adjusted from 20%~100%.

Sweep frequency: different sweep frequency can be set, and sweep frequency is 20%~100%

Alarm: overcurrent, overheating alarm, output under-power alarm, output open-circuit alarm, output frequency drift alarm, remote control when communication overtime alarm

Timing: ultrasonic generator can be set to work regularly, timing range (1S~9999S)

Temperature control (optional): collect the temperature of the ultrasonic tank, control the heater through relay, maintain the temperature of the tank within the set temperature range of (+2%).

Remote control: RS485 interface, remote control panel, to achieve power, timing, temperature and other remote settings, fault display, switch control;

Energy control: control the constant power output of ultrasonic transducer.

The frequency, power and corresponding state can be displayed at work.

Multi lingual interface, communication function and interface with PC.

He is a circuit board.

The ultrasonic output power is continuously stepless and adjustable, with a range of 10~100%.

The ten bit LED light emitting row is displayed step by step, which can directly grasp the size of ultrasonic output power.

Type	Power（W）	Frequency (KHz)	Transducer numbers	Size
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE All of machine are available for opening remote control function to connect with your own PLC system
UCE-NT300	300W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	3-6	300x360x150
UCE-NT600	600W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	6-12	300x360x150
UCE-NT900	900W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	9-18	300x360x150
UCE-NT1000	1000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	10-20	300x360x150
UCE-NT1200	1200W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	12-24	300x360x150
UCE-NT1500	1500W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	15-30	300x360x150
UCE-NT1800	1800W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	18-36	300x360x150
UCE-NT2000	2000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	20-40	300x360x150
UCE-NT2400	2400W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	24-48	300x360x150
UCE-NT3000	3000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	50-60	300x360x150
High Frequency	300W-1200W	65-80khz
High Frequency	300W-1200W	120-135khz
