ultrasonic bubble generator with industry ultrasonic cleaner

ultrasonic bubble generator with industry ultrasonic cleaner,ultrasonic bubble generator with industry ultrasonic cleaner,ultrasonic bubble generator with industry ultrasonic cleaner,ultrasonic bubble generator with industry ultrasonic cleaner

Item ID #

Ask a Question FAQ & Help Payment Methods Shipping Estimator Email To Us Print This Page

Description

ultrasonic bubble generator with industry ultrasonic cleaner

The following three points can be embodied in the function of ultrasonic cleaning.

(1) hole action

When strong ultrasonic radiation into the liquid, the cleaning fluid to static pressure (a standard pressure) as the center of change, when the pressure below zero pressure, dissolved in the liquid oxygen will form a tiny bubble nucleus, resulting in numerous similar to the vacuum of small cavities (cavities). The small cavities in the normal pressure of ultrasonic wave are crushed in the adiabatic compression state. This strong shock wave occurring at the moment of crushing can destroy the pollutants directly and disperse them in the liquid, forming the cleaning mechanism. In the test, this powerful cleaning effect can destroy hundreds of small holes in aluminum foil in dozens of seconds.

The cleaning effect of cavitation is better. Usually the cleaning of mechanical parts is carried out in the frequency of 28KHZ ~ 50KHZ. The ultrasonic intensity of the cleaning machine is mostly set at 0.5~1w/cm2.

(2) acceleration

When the cleaning liquid is irradiated by ultrasonic wave, the molecule vibrates. The vibration acceleration is 103 times that of gravity at 28KHZ and 105 times that at 950KHZ. By this strong acceleration, the contaminated surface can be stripped and cleaned. However, the 950KHZ ultrasonic does not produce holes, and is not suitable for oil cleaning. It can only be used in semiconductor manufacturing in the electronic industry to clean the pollution of submicron particles.

Type	Power（W）	Frequency (KHz)	Transducer numbers	Size
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE All of machine are available for opening remote control function to connect with your own PLC system
UCE-NT300	300W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	3-6	300x360x150
UCE-NT600	600W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	6-12	300x360x150
UCE-NT900	900W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	9-18	300x360x150
UCE-NT1000	1000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	10-20	300x360x150
UCE-NT1200	1200W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	12-24	300x360x150
UCE-NT1500	1500W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	15-30	300x360x150
UCE-NT1800	1800W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	18-36	300x360x150
UCE-NT2000	2000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	20-40	300x360x150
UCE-NT2400	2400W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	24-48	300x360x150
UCE-NT3000	3000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	50-60	300x360x150
High Frequency	300W-1200W	65-80khz
High Frequency	300W-1200W	120-135khz
