28khz/25khz ultrasonic transducer driver circuit
In order to improve the complex defects in the adjustment process, this machine upgrades and updates the circuit, program and components. After more than two years of repeated testing and factory practice, the new intelligent digital display ultrasonic generator with complete functions and simple adjustment is introduced
(1) With timing function, it can realize timing switch on and off;
(2) It has the function of sweeping frequency to realize the cleaning of sweeping frequency;
(3) The ultrasonic frequency, output wattage and current can be displayed at the same time, which is more intuitive and clear;
(4) It has over-current, overload and overheating protection functions;
(5) This machine adopts high-power IBGT amplification output to drive the transducer, which makes the ultrasonic effect stronger in the liquid cavitation;
(6) This machine adopts PWM control chip to realize high efficiency dynamic response;
Type |
Power(W) |
Frequency (KHz) |
UCE-220V-PCB200W |
200 |
20khz,25khz,28khz,33khz,40khz
Frequency is adjustable
50khz,54khz,60khz,68khz,80khz,90khz
100khz,120khz,135khz,165khz,200khz |
UCE-220V-PCB300W |
300 |
20khz,25khz,28khz,33khz,40khz
Frequency is adjustable
50khz,54khz,60khz,68khz,80khz,90khz
100khz,120khz,135khz |
UCE-220V-PCB400W |
400 |
20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
UCE-220V-PCB500W |
500 |
20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
UCE-220V-PCB600W |
600 |
20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
28khz/25khz ultrasonic transducer driver circuit
