Ultrasonic impedance analyzer



1、 Instrument overview



Ultrasonic impedance analyzer is also called ultrasonic frequency measuring instrument, ultrasonic transducer parameter analyzer, ultrasonic transducer impedance tester and ultrasonic performance analyzer. The instrument is composed of hardware and software. The product can measure and evaluate the parameters, quality and comprehensive performance of ultrasonic tool head (ultrasonic mold), piezoelectric ceramic chip, piezoelectric transducer, ultrasonic cleaning machine, ultrasonic welding machine, ultrasonic pulverizer, ultrasonic processing equipment and other devices and equipment.



2、 Characteristics of impedance tester

1. High precision of impedance measurement, accurate to 0.1Hz

2. It is easy to judge defects by admittance circle and logarithmic curve

3. The test results completely distinguish the vibration point and the half power point

4. Test data computer can store and print infinitely and trace data source

5. Automatic filtering and statistics, parameter filtering can be set

6. The automation operation efficiency is high, the operation is simple, and there is no artificial error

7. It is simple, easy to use, the combination of indicators and graphics, accurate parameters, low price and strong guidance for production. Transducer impedance tester can measure and evaluate the parameters and performance of piezoelectric ceramic chip, piezoelectric transducer, ultrasonic cleaning machine, ultrasonic welding machine, ultrasonic pulverizer, ultrasonic processing equipment and other devices and equipment. It is intuitionistic and practical to judge by admittance circle diagram and conductance curve.
