The anti dissector can accurately measure the impedance scale and wide frequency scale. It uses the object to have different conductive effect. When a fixed low-level current is added to the surface of the object, the impedance is used to calculate the various equipment, equipment parameters and functions of the object.

Principle of impedance analyzer

Impedance analyzer can be measured and identified to match the circuit

As for piezoelectric ceramic chip, we can directly judge whether the equipment is good or bad from the admittance circle diagram and logarithmic coordinates. If the internal layer of the ceramic chip is layered, or there are cracks, the logarithmic curve will show multi peaks, and the admittance circle will show multiple parasitic circles

Whether the planning, processing and installation of the horn is reasonable or defective can be seen directly on the guide circle diagram

About the production and processing of ultrasonic welding machine, the status of the welding machine is analyzed by using the results of admittance circle. Through the analysis of parameters and graphics, the problems existing in the welding machine are found
